Features
1. Automatic waveform and status configuration
2. Storage of waveforms, setups and interfaces; waveforms and setups reproduction
3. Print Screen function
4. Fine window extension; precise analysis of waveform details and overview
5. Unique waveform recording, storage and replay function
6. HD color 5.7 inches LCD panel at 320 x 240 pixels aspect ratio
7. Multiple waveform mathematics functions (including add, subtract, multiply and divide)
8. Multi-meter function
9. USB drive system software upgrade
|
Specifications |
UTD1202C |
|
|
Channels |
2 |
|
|
Bandwidth |
200MHz |
|
|
Sampling Rate |
1GS/s |
|
|
Rise Time |
≤1.8ns |
|
|
Memory Depth |
7.5kpts |
|
|
Vertical Sensitivity |
5mV-50V/div |
|
|
Time-based Range |
2ns/div-50s/div |
|
|
Storage |
Setup, Waveform, Bitmap |
|
|
Trigger Modes |
Edge, Pulse, Video and Alternative |
|
|
Interface |
USB HOST / USB OTG (Optional) |
|
|
Multi-meter Specifications |
Range |
Best Accuracy |
|
DC Voltage (V) |
600mV/6V/60V/600V/1000V |
±(1%+5) |
|
AC Voltage (V) |
600mV/6V/60V/600V/700V |
±(1.2%+5), Frequency: ＜200Hz |
|
±(1.5%+5), Frequency: ≥200Hz |
||
|
DC Current (A) |
6mA/60mA/600mA |
±(1.2%+5) |
|
6A |
±(1.5%+5) |
|
|
AC Current (A) |
6mA/60mA/600mA |
±(2%+5) |
|
6A |
±(2.5%+5) |
|
|
Resistance (Ω) |
6kΩ/60kΩ/600kΩ |
±(1.2%+5) |
|
600Ω/6MΩ/60MΩ |
±(1.5%+5) |
|
|
Capacitance (F) |
6nF/6mF |
±(5%+10) |
|
60nF/600nF/6μF/60μF/600μF |
±(4%+5) |
|
|
Display Count |
6000 |
|
|
Auto Range |
√ |
|
|
General Characteristics |
||
|
Power |
Lithium Battery: 7.4V 4400mAh; |
|
|
Display |
5.7 inches TFT LCD, QVGA (320×240) |
|
|
Product Color |
Red and grey |
|
|
Product Net Weight |
1.8kg |
|
|
Product Size (W×H×D) |
268mm × 168 mm × 60mm |
|
|
Standard Accessories |
Probe×2 (1×,10× Switchable), Current Voltage Convertor×2, Power Cord, DC Adaptor, Test Lead, PC Software CD |
|
|
Standard Individual Packing |
Gift Box, Carrying Bag, English Manual |
|
|
Standard Quantity Per Carton |
4pcs |
|
|
Standard Carton Measurement (L×W×H) |
500mm × 400mm × 320mm |
|
|
Standard Carton Gross Weight |
10.8kg |
|
|
Optional Accessory |
||
|
USB OTG |
||
