IR Thermometers

UT301 A/C

Features

1. Dual display (MAX/MIN/AVG/DIF with real-time)

2. ℃/℉ options

3. Optional (on/off) laser pointer

4. Auto power off, data hold

5. Adjustable emissivity

6. Tripod installation hole and lock measurement function for continuous measurement

7. LCD backlight

Specifications	Range
Model	UT301A	UT301C
Temperature Range	-18°C~350°C	-18°C~550°C
Temperature Range	0°F~662°F	0°F~1022°F
Accuracy	±1.8°C or ±1.8%	±1.8°C or ±1.8%
Repeatability	±0.5°C or ±0.5%	±0.5°C or ±0.5%
Resolution	0.1°C/0.1°F	0.1°C/0.1°F
Distance to Spot Size	12: 1	12: 1
Response Time	250ms (95% of reading)	250ms (95% of reading)
Emissivity	0.10~1.0 Adjustable	0.10~1.0 Adjustable
Laser Type	Class 2 (Ⅱ)	Class 2 (Ⅱ)
Laser Power	＜1mW	＜1mW
Laser Wavelength	630nm~670nm	630nm~670nm
Spectral Response	8μm~14μm	8μm~14μm
Features
°C/°F Selection	√	√
Laser Switch (ON/OFF)	√	√
Display Hold (s)	8 seconds	8 seconds
Data Hold	√	√
Auto Power Off	√	√
Low Battery Indication	√	√
MAX Mode	√	√
MIN Mode	√	√
DIFF Mode	√	√
AVG Mode	√	√
LCD Backlight	√	√
Power-off Memory	√	√
Tripod Mount	√	√
General Characteristics
Power	9V battery (6F22)
LCD Size	32mm×29mm
Product Color	Red and grey
Product Net Weight	270g
Product Size	169mm×138mm×53mm
Standard Accessories	Battery
Standard Individual Packing	Blister, English Manual
Standard Quantity Per Carton	20pcs
Standard Carton Measurement	605×360×468mm (0.101 CBM Per Standard Carton)
Standard Carton Gross Weight	12.3kg
