Clamp meter

UT216D

Main features

1. True RMS; OLED display

2. Auto range, 3 times/s sampling rate

3. MAX/MIN/Relative modes

4. K-type temperature probe

5. Data hold, LCD backlight, auto power o?

6. 400Hz measurement; Flashlight

7. NCV, non-contact AC voltage testing

8. VFC, low pass ?lter

9. Zeroing function

10. Inrush current

11. Analog bar graph

Specifications	Range	Best Accuracy
Model		UT216D
AC Current (A)	60A/600A	±(2.5%+5)
AC Current Frequency (Hz)		40Hz ~ 400Hz
DC Current (A)	60A/600A	±(2.5%+5)
AC Voltage (V)	6V/60V/600V/750V	±(1.2%+5)
AC Current Frequency (Hz)		40Hz ~400Hz
DC Voltage (V)	600mV/6V/60V/600V/1000V	±(0.8%+1)
Resistance (Ω)	600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ	±(1%+2)
Capacitance (°F)	99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF/60mF	±(4.0%+5)
Frequency (Hz)
Temperature (°C)	-40°C ～ 1000°C	±(2.0%+5)
Temperature (°F)	-40°F ～ 1832°F	±(2.0%+10)
Features
Display Count		6000
Auto Range		√
Jaw Capacity		30mm
True RMS		√
Diode	Around 3.0V	√
VFC		√
NCV		√
Data Hold		√
Relative Mode		√
MAX/MIN		√
Inrush Current		√
LCD Backlight
OLED Display		√
Analogue Bar Graph		21
Flashlight		√
Auto Power Off	Around 15 minutes	√
Continuity Buzzer		√
Low Battery Indication	≤3.6V	√
Input Protection		√
Input Impedance for DCV	≥10MΩ	√
General Characteristics
Power	AAA 1.5V x 3
LCD Size	38mm x 24 mm
Product Color	Red and Grey
Product Net Weight	231.7g
Product Size	220mm x 75mm x 40mm
Standard Accessories	Batteries, Test Lead, Point Contact Temperature Probe
Standard Individual Packing	Gift Box, Carrying Bag, English Manual
Standard Quantity Per Carton	40pcs
Standard Carton Measurement	485mm × 320mm × 385mm
Standard Carton Gross Weight	20kg
