Digital multimeter

  • DT9201A-2
DT9201A-2

DT9201A-2

  • Product description: Digital Multimeters
  • INQUIRY
Characteristic

Moving large LCD for different angle reading need
Full protection design against burn
Data hold function for easy reading after measurement
With PVC shockproof holster
With temperature test function

Technology features

DCV: 200m-2-20-200-1000V                                ±0.5%
ACV: 200m-2-20-200-750V                                   ±1.0%
DCA: 20u-200u-2m-20m-200m-2A-20A             ±1.8%
ACA: 20u-200u-2m-20m-200m-2A-20A             ±2.0%
Resistance: 200-2K-20K-200K-2M-20MΩ         ±1.0%

Description

LCD size: 67x32mm
Max display: 1999
Low battery indication: yes
Overload protection: yes
Diode test: yes
Continuity buzzer test: yes
Transistor test: yes
Auto power off: yes
Data hold: yes
Power supply: one 6F22 9V Battery
Product size:190x89x33mm
Product weight: about 282g (with holster)
Standard Accessories: meter (with battery), holster, test lead, manual
